Chauvet DJ Obey 10 2U DMX Desk
Obey 10 is the compact end of the Obey console range, addressing 128 channels across up to eight fixtures at 16 channels each. That covers a typical mobile rig of moving heads and washes without the desk space of a full console.
It stores six sets of chases holding up to 999 scenes each, which is far more depth than the fixture count suggests and lets a whole evening be programmed in advance. Any fixture can be grabbed live and overridden mid-chase, and movement can be beat-activated or set to run automatically with no operator input. It is 2U at 19 x 3.5 x 3.5 inches, weighs 3.9 lb, connects over 3-pin XLR, and runs from a 9 VDC supply.
| DMX Channels | 128 |
|---|---|
| DMX Connectors | 3-pin XLR |
| Rackmount | 2U |
| Input Voltage | 9 VDC, 500 mA (external power supply: 100 to 240 VAC, 50/60 Hz) |
| Size | 19 x 3.5 x 3.5 in (483 x 89 x 89 mm) |
| Weight | 3.9 lb (1.8 kg) |
