BZBGear BG-EXH-50C HDMI Extender over Cat5e/6/7

The EXH-50C is the small, inexpensive pair for a short run - a projector at the back of a room, a display in the next office. It carries 4K60 4:4:4 to 50 m on Cat5e and 60 m on Cat6 or better, and drops to 70 m at 4K30 and 1080p.

Each unit is 61 mm wide and weighs about a third of a pound, so it hides behind a display plate. Power over Cable runs the receiver from the transmitter, an HDMI loop-out on the transmitter keeps a local monitor, and IR passes in both directions.

HDMI compliance	HDMI 2.0
HDCP compliance	HDCP 2.2 / HDCP 1.4
Video bandwidth	18Gbps
Video resolution	Up to 4K@60Hz 4:4:4
Colour space	RGB / YCbCr 4:4:4, YCbCr 4:2:2/4:2:0, YUV 4:4:4
HDMI audio formats	LPCM 2.0/2.1/5.1/6.1/7.1, Dolby Digital, Dolby TrueHD, Dolby Digital Plus(DD+), DTS-ES, DTS HD Master, DTS HD-HRA, DTS-X
Transmitter connections	Inputs: 1x HDMI Type A [19-pin female] 1x SERVICE [Micro USB, Update port] Outputs: 1x HDMI Type A [19-pin female] 1x IR OUT [3.5mm Stereo Mini-jack] 1x CAT OUT [RJ45, 8-pin female]
Receiver connections	Inputs: 1x IR IN [3.5mm Stereo Mini-jack] 1x CAT IN [RJ45, 8-pin female] 1x SERVICE [Micro USB, Update port] Outputs: 1x HDMI Type A [19-pin female]
Power supply	Input: AC 100 - 240V 50/60Hz Output: DC 12V/1A
Dimensions	Transmitter / Receiver: 2.4" (W) x 3.5" (D) x 0.7" (H) [61mm (W) x 88mm (D) x 18mm (H)]
