BZBGear BG-4K-VP1616 16x16 Seamless Matrix and Video Wall Processor

The BG-4K-VP1616 routes any of sixteen HDMI inputs to any of sixteen outputs at up to 4K60 4:4:4, and every output is mirrored on a Cat output that reaches 70 m over Cat6/7 without an outboard extender. Switching is seamless, so sources change without a black frame in front of an audience.

The same frame builds video walls with rotation and bezel correction, and runs multiview layouts including picture-in-picture, picture-and-picture, quad view and up to sixteen sources on one screen. Bandwidth is 18 Gbit/s with HDCP 2.3 and 1.4, and control comes from the front panel, IR, RS-232 or the network.
