BZBGear BG-4K-1616MA 16x16 HDMI Matrix Switcher

Sixteen in, sixteen out is head-end territory: a stadium concourse, a trading floor, a large house of worship. The 4K-1616MA routes any of sixteen HDMI sources to any of sixteen outputs independently, at up to 4K60 4:4:4 with the full set of HDR formats.

Each output has an RCA audio breakout. Control is by front panel, TCP/IP over RJ45, RS-232 on a DB9 or an IR extender, and the unit occupies a single rack width at 256 mm deep. Maximum draw is just under 100 watts.

HDMI compliance	HDMI 2.0b
HDCP compliance	HDCP 2.2
Video bandwidth	18Gbps
Video resolution	Up to 4K60Hz 4:4:4 All available resolutions are shown in the table below
HDR formats	HDR, HDR10, HDR10+, Dolby Vision LLM, HLG
Input ports	16x INPUT [HDMI Type A, 19-pin female]
Video output ports	16x OUTPUT [HDMI Type A, 19-pin female]
Audio output ports	16x AUDIO OUT [RCA]
Power consumption	99.6W (Max)
Dimensions (W x D x H)	17in x 10in x 1.8in [440mm x 256mm x 44.5mm]
Weight	11 lbs [4.9kg]
