Blaze Audio PowerZone Connect 1008 1000 W 8-Channel Install Amplifier

The PowerZone Connect 1008 packs eight amplifier channels and 1000 watts of total system power into a single rack space, 17.3 inches wide and 8.4 pounds. In low impedance it produces 8 x 125 W into 4 or 8 ohms; in constant voltage it produces 4 x 250 W at 70V or 100V, with power sharing across channels so zones drawing less than their rated power free up capacity for others. That density makes it a natural fit for restaurants, retail, and multi-room commercial spaces with more zones than a quarter-rack amp can cover.

Built-in PowerZone Control DSP handles full-matrix routing and processing from a web browser, with no separate software to install. Power consumption is rated at 300 W, and the chassis is a standard 1U rack size. This model does not include Dante networking; for audio-over-IP, step up to the D-suffixed PowerZone Connect models.

Total System Power	1000 W
Channel Configuration	Lo-Z 8 x 125 W at 4/8 ohms; Hi-Z 4 x 250 W at 70V/100V, power sharing
Output Power at 4 / 8 ohms	8 x 125 W
Output Power at 70V / 100V	4 x 250 W
Power Consumption	300 W
Dante Compatibility	No
Form Factor	1U rack, 17.3 x 1.7 x 12.6 in (439 x 43 x 320 mm)
Weight	8.4 lb (3.81 kg)
