Blaze Audio PowerZone Connect 252 250 W 2-Channel Install Amplifier

The PowerZone Connect 252 is the smallest two-channel amplifier in the Connect line, built for a single small zone that still benefits from networked DSP control. In low impedance it produces 2 x 125 W into 4 or 8 ohms; in constant voltage it produces 1 x 250 W bridged at 70V or 100V. At 8.7 by 1.7 by 8.4 inches and 4.41 pounds, it is the most compact chassis in the family.

Built-in PowerZone Control DSP runs full-matrix routing and processing from a web browser, with no separate software required. Power consumption is rated at 75 W, and this model does not include Dante networking.

Total System Power	250 W
Channel Configuration	Lo-Z 2 x 125 W at 4/8 ohms; Hi-Z 1 x 250 W at 70V/100V, power sharing
Output Power at 4 / 8 ohms	2 x 125 W
Output Power at 70V / 100V	1 x 250 W
Power Consumption	75 W
Dante Compatibility	No
Form Factor	1U half rack, 8.7 x 1.7 x 8.4 in (221 x 43 x 213 mm)
Weight	4.41 lb (2.0 kg)
