AJA KUMO 3232-12G Compact 2RU 32x32 12G-SDI Router

The KUMO 3232-12G is a 32x32 SDI router that packs full 12G capacity into a compact 2RU chassis, supporting 12G, 6G, 3G, and 1.5G-SDI across all 32 inputs and 32 outputs. It mirrors the physical form of AJA's production-proven KUMO 3232 while adding 12G-SDI, so a single cable per port carries 4K/UltraHD and cable runs shrink accordingly. Ganged dual and quad-port routing groups inputs and outputs together for Dual Link, Quad Link 4K/UltraHD, and 8K workflows.

Control is flexible: an embedded web server allows HTTP control and monitoring from any browser with no extra software, alongside physical KUMO CP and CP2 control panels, and a USB port is provided for setting IP addresses with AJA's eMini-Setup software. Eight salvos per router let operators recall predefined routing configurations instantly. The unit ships with one power supply, with a redundant supply available as an option.
