Allen & Heath ZED60-14FX Mixer

The ZED60-14FX steps up to eight mic/line channels while keeping the 60mm faders, onboard effects, and USB recording of the ZED60 range. Each mic/line channel carries switchable 48V phantom power and 3-band EQ with a sweepable midrange, and the two high-impedance instrument inputs with a 26 dB boost switch let a guitar or bass plug straight in without a separate DI. It is a portable desk with enough inputs for a full small band.

Sixteen onboard digital effects add reverb, delay, chorus, flanger, and doubler, and a 2-in/2-out USB port sends CD-quality audio to a Mac or PC for recording and returns playback. Two stereo TRS inputs plus an RCA pair take backing tracks and media players, XLR main outputs carry insert points for outboard gear, and the 60mm faders give more travel and finer control than compact knob mixers.
