Sennheiser SL MCR DW Multi-Channel Receiver
The SL MCR is what a meeting room wants instead of a rack: a 180 x 180 x 45 mm box that mounts on a wall or above a ceiling, takes two or four SpeechLine Digital Wireless channels, and gets its power and its audio out over one Cat cable. PoE in, Dante out on primary and secondary ports, and an automixer already running inside so a four-mic room does not need an outboard one.
The 1.9 GHz link handles its own frequency and interference management with TDMA and space diversity, which is the reason SpeechLine gets specified in buildings where nobody will ever coordinate a band plan. Audio is 20 to 20,000 Hz with more than 120 dB(A) of dynamic range at 23 ms latency, and the link is AES 256 encrypted. The two- and four-channel versions are otherwise identical.
- Dimensions180 x 180 x 45 mm (incl. wallmount)
- RF output power back channeladaptive or manual, up to 250 mW (country-specific)
- Storage temperature-20 °C to +70 °C (-4 °F to 158 °F)
- AF frequency response20 to 20,000 Hz
- Dynamic range> 120 dB(A)
| Version (SL MCR 2 DW-4) | 2-channel version |
|---|---|
| Version (SL MCR 4 DW-4) | 4-channel version |
| AF Frequency Response | 20 to 20,000 Hz |
| Dynamic Range | > 120 dB(A) |
| THD (1 kHz) | Typ. 0.1 % |
| Audio Sampling | 24 bit/48 kHz |
| Signal-to-Noise Ratio | > 90 dB(A) |
| Encryption | AES 256 |
| RF Frequency Range (USA) | 1,920 - 1,930 MHz |
| Modulation | GFSK with back channel |
| Transmission Method | TDMA, space diversity |
| Latency | 19 ms |
| RF Sensitivity | < -90 dBm |
| RF Output Power Back Channel | Adaptive or manual, up to 250 mW (country-specific) |
| Network Protocol | Media Control Protocol, UDP IPv4 (DHCP, Manual)/IPv6, mDNS (switchable) |
| Power Supply | IEEE 802.3af Class 3 |
| Audio Outputs | One 3-pin socket (suitable for Phoenix Contact MCVW 1.5-3-ST-3.81); Two Dante™ Digital Audio Network sockets (RJ-45) |
| Weight | 650 g (incl. wallmount); 560 g (without wallmount) |
| Dimensions | 180 x 180 x 45 mm (incl. wallmount) |
| Operating Temperature | -10 °C to +45 °C (14 °F to 113 °F) |
| Storage Temperature | -20 °C to +70 °C (-4 °F to 158 °F) |
| Relative Air Humidity | Max. 95 % |
| Source | Spec sheet (PDF) on sennheiser.com |
