Panelix Pro Industrial Panel PC, Intel Core i5
The Pro tier is the Panelix panel PC with an Intel Core i5 in it, which matters when the station is running SCADA, a full MES client, or several dashboards at once rather than a single kiosk application. Everything else follows the same industrial rules as the rest of the line: projected capacitive touch, a sealed all-in-one enclosure, VESA mounting, 24/7 continuous operation, and wide temperature operation.
Five sizes run from 15.6 inches up to 23.8 inches, with the 15.6 inch model at 1920 x 1080 and weighing about 5 lbs. Panelix positions the Pro at production lines, warehouse operations, food processing, packaging, and supervisory stations, the places where an operator interacts with the screen all shift and the machine cannot be rebooted casually.
| Type | All-in-one industrial panel PC |
|---|---|
| Processor | Intel Core i5 |
| Operating System | Windows |
| Touch | Projected capacitive (PCAP) |
| Screen Sizes | 15.6, 17.3, 18.5, 21.5, and 23.8 in |
| Resolution | 1920 x 1080 (15.6 in model) |
| Weight | Approximately 5 lbs (15.6 in model) |
| Duty Rating | 24/7 continuous operation; wide temperature operation |
| Mounting | VESA mount compatible |
