Name: Magewell Ultra Encode HDMI Plus Streaming Encoder (53150)
Brand: Magewell
SKU: 53150
Price: 655.00 USD
Availability: InStock

Ultra Encode HDMI Plus is a flexible and Universal Streaming and Recording Encoder. Connections: 2 x HDMI ports 1 x Input; 1 x Loop-through; 1 x 3.5mm LINE IN; 1 x 3.5mm LINE OUT; 1 x USB Type-A. Signal handling: Video Bitrate: NDI HX3: up to 62.0Mbps, down to 1.5Mbps; Others: up to 32.0Mbps, down to 256kpbs; Dual-stream encoding: main stream and sub stream.

Networking: Ethernet: 1x RJ45 port, 10/100/1000 Mbps Base-T; IEEE 802.3af PoE; Wi-Fi: 802.11 a/b/g/n/ac, Station and AP modes supported. Setup and monitoring: Access Web UI via PC and smartphone; View real-time device status; Preview encoded video; Set input sources; Customize encoding parameters. It measures 106.6mm x 106.2mm x 25mm. Power: DC 5V/3A; Max power consumption: 8.68W. In the box: 1 x 5V Power Adapter; 1 x HDMI Cable; 1 x USB Type A to Type B cable; 1 x Wi-Fi Antenna; 1 x T-bracket.

Part Number	53150
Input/Output Ports	2 x HDMI ports 1 x Input; 1 x Loop-through; 1 x 3.5mm LINE IN; 1 x 3.5mm LINE OUT; 1 x USB Type-A
Encode	Video Bitrate: NDI HX3: up to 62.0Mbps, down to 1.5Mbps; Others: up to 32.0Mbps, down to 256kpbs; Dual-stream encoding: main stream and sub stream
Network Connections	Ethernet: 1x RJ45 port, 10/100/1000 Mbps Base-T; IEEE 802.3af PoE; Wi-Fi: 802.11 a/b/g/n/ac, Station and AP modes supported; 4G/5G USB modem (not supplied); USB Net
Record	Supports setting and managing recording function and tasks; Supports recording to local storage (128 GB) Supports format and performance test
Control	Access Web UI via PC and smartphone; View real-time device status; Preview encoded video; Set input sources; Customize encoding parameters
Form Factor	106.6mm x 106.2mm x 25mm
Power	DC 5V/3A; Max power consumption: 8.68W
