Crestron DM-NVX-E760 DM NVX 4K60 4:4:4 HDR Network AV Encoder with DM Input

The Crestron DM-NVX-E760 is a DM NVX 4K60 4:4:4 HDR Network AV Encoder with DM Input. DM NVX carries the signal as a stream over standard Gigabit Ethernet, which makes the network switch the matrix and lets a system grow by adding endpoints instead of replacing a chassis.

Audio formats are primary multichannel (up to 8-channel LPCM or encoded HBR 7.1 surround sound). Copy protection is HDCP 2.3, AES-128, PKI. Streaming uses RTP, SDP. It is set up and monitored from the same Crestron control program and XiO Cloud account as the rest of the estate.

Video ResolutionsUp to 4096x2160@60Hz (DCI 4K60), 4:4:4 color sampling, HDR10, and Deep Color support
Audio FormatsPrimary multichannel (up to 8-channel LPCM or encoded HBR 7.1 surround sound)
Bit RatesFixed: 200 to 950 Mbps - user specified, Adaptive: Dependent on input resolution of the stream, or Variable: Less than 150 Mbps to maximum of 750 Mbps, dependent on content and input resolution of the stream
Streaming ProtocolsRTP, SDP
Copy ProtectionHDCP 2.3, AES-128, PKI
Input Signal TypesDM 8G+ and HDBaseT with HDR10, Deep Color, and 4K60 4:4:4 support; DM Essentials with 4K60 4:2:0 support
ContainerMPEG-2 transport stream (.ts)
Session InitiationMulticast via secure RTSP
Crestron DM NVX® E760: Technical Deep Dive With Demo
Crestron DM-NVX-E760: A First in Interoperability
