CAD Audio CAD Astatic WM-625 Wall Mounted Omnidirectional Dynamic Microphone

The WM-625 is the switchless counterpart to the WM625S, a wall-outlet-box dynamic microphone for permanent paging installations where the muting or push-to-talk function is handled by an external console instead of the mic itself. It shares the same omnidirectional dynamic capsule and wall-mount form factor.

That makes it the right choice for a paging system whose head-end already gates the mic input, keeping the wall unit itself simple and less likely to need service.

TypeDynamic wall-mounted paging microphone
Polar PatternOmnidirectional
Operating PrincipleMoving coil dynamic
Frequency Response300 Hz - 4 kHz
Sensitivity-42 dBV (7.9 mV) @ 1 Pa
Impedance500 ohms
MountingWall outlet box
