Aviom A360 Personal Mixer

The A360 is the larger Aviom personal mixer, running a 36-channel mix engine that handles up to 17 mono or stereo sources plus an ambience channel. The One-Touch Ambience button brings in either a network audio channel or the mixer's onboard microphone, which is what keeps an in-ear player connected to the room instead of sealed off from it.

Outputs cover every monitor arrangement on a stage: a 1/4 inch TRS stereo out, a 1/8 inch TRS stereo out for consumer in-ears, and a balanced XLR mono line output for a wedge or a shaker. The headphone amplifier delivers 1.0 watt into 100 ohms. A-Net comes in on an EtherCon RJ45 supporting both Pro16 and Pro16e. The chassis is 11 x 6.9 x 1.835 inches and 3.4 lb.

Mix Engine	36-channel engine, up to 17 mono or stereo sources plus ambience
A-Net	1 A-Net In, EtherCon RJ45; supports Pro16 and Pro16e
Audio Outputs	1/4 in TRS stereo, 1/8 in TRS stereo, XLR balanced mono line level
Headphone Output	1.0 watt at 100 ohms
Ambience	One-Touch Ambience using network audio or the onboard mic
Power	Optional universal switching supply, 100 - 240 V in, 24 VDC 0.5 A out
Dimensions	11 in wide x 6.9 in deep x 1.835 in high
Weight	3.4 lb (1.54 kg)
