AtlasIED TSD-MIX41 4 x 1 Mic/Line Mixer
The AtlasIED TSD-MIX41 is a 4 x 1 mic/line mixer. The TSD-MIX41 4x1 mic/line mixer is ideal for applications where multiple mic or line sources need to be sub mixed or summed. In house of worship applications the TSD-MIX41 is especially useful for combining similar sources such as choir microphones to a single mixer channel. Published frequency response is 20Hz - 20kHz (+/-1dB).
The unit also works well as a stand-alone mic/line mixer that can be easily interfaced with AtlasIED amplifiers. Other applications include restaurants, conference rooms, and schools. AtlasIED lists four (4) balanced mic/line inputs; four (4) professional grade microphone preamps with switchable 24V phantom power; up to 50dB mic gain per input; 12dB/octave low cut filter @ 125Hz. It measures 1.5" high, 4" wide, and 2.5" deep. It carries a manufacturer warranty of 36 months from date of purchase.
| Part Number | TSD-MIX41 |
|---|---|
| Input impedance | 1.2KΩ Balanced, 600Ω Unbalanced |
| THD | .06% & 1kHz |
| Phantom Power | 24VDC Defeatable |
| Low Cut Filter | 125Hz/12dB Defeatable |
| Line Input Level | 1V (0dBV) Balanced 2V (+6dBV) Balanced Output |
| Mic Input Level | 46dB Gain 10mV (-40dBV) Balanced |
| Output impedance | 300Ω Balanced, 150Ω Unbalanced |
| Line Output Level | 1V (0dBV) In |
| Frequency Response | 20Hz - 20kHz (+/-1dB) |
| Signal to Noise Ratio Line to Line | 85dBV |
| Signal to Noise Ratio Mic to Line | 78dBV |
| 24VDC Power Requirements | 60mA |
| Height | 1.5" (3.81 cm) |
| Width | 4" (10.16 cm) |
| Depth | 2.5" (6.35 cm) |
| Weight | 6oz., .165kg |
| Voltage Compatibility | 24V |
| Warranty Period | 36 months from date of purchase |
