AtlasIED TSD-MIX31RL 3 x 1 Mic/Line Mixer
The AtlasIED TSD-MIX31RL is a 3 x 1 mic/line mixer. The TSD-MIX31RL 3x1 mic/line mixer includes two mic/balanced line inputs via removable Phoenix style connectors and a stereo summing dual RCA input. Switchable phantom power is provided for both mic inputs to facilitate condenser microphones. Published frequency response is 20Hz - 20kHz (+/-1dB).
The high quality, low noise internal mic preamps ensure clarity and quiet operation without unwanted coloration. A 12dB / octave high pass filter @ 125Hz also is available on each input to minimize bass rumble and low frequency feedback. AtlasIED lists two (2) balanced mic/line inputs; high gain (50dB) microphone preamps; switchable 24V phantom power; one (1) unbalanced summing dual RCA line input. It measures 1.5" high, 4" wide, and 2.5" deep. It carries a manufacturer warranty of 36 months from date of purchase.
| Part Number | TSD-MIX31RL |
|---|---|
| Unbalanced Input Impedance | 10KΩ |
| THD | .06% & 1kHz |
| Input Level | 316mV (-10dBV) |
| Balanced Input Impedance | 1.2KΩ Balanced, 600Ω Unbalanced |
| Phantom Power | 24VDC Defeatable |
| Low Cut Filter | 125Hz/12dB Defeatable |
| Line Input Level | 1V (0dBV) Balanced 2V (+6dBV) Balanced Output |
| Mic Input Level | 46dB Gain 10mV (-40dBV) Balanced |
| Output impedance | 300Ω Balanced, 150Ω Unbalanced |
| Line Output Level | 1V (0dBV) In |
| Frequency Response | 20Hz - 20kHz (+/-1dB) |
| Signal to Noise Ratio Line to Line | 85dBV |
| Signal to Noise Ratio Mic to Line | 70dBV |
| 24VDC Power Requirements | 60mA |
| Height | 1.5" (3.81 cm) |
| Width | 4" (10.16 cm) |
| Depth | 2.5" (6.35 cm) |
| Weight | 6oz., .165kg |
| Voltage Compatibility | 24V |
| Warranty Period | 36 months from date of purchase |
