Audio-Technica ATW-3212/C510EE1 3000 Series Wireless Handheld System (ATW-C510 Dynamic, EE1 Band)
The ATW-3212/C510EE1 is a fourth-generation 3000 Series handheld wireless system built around the ATW-C510 interchangeable capsule. It pairs the ATW-R3210 true-diversity UHF receiver with the ATW-T3202 handheld transmitter, fitted with the ATW-C510 cardioid dynamic capsule (equivalent to the ATM510) for smooth, natural vocal reproduction and strong off-axis rejection to fight feedback.
Because the capsule threads on an industry-standard mount, the handheld can be re-headed with other A-T capsules as needs change. The fourth-generation platform provides 60 MHz of UHF tuning bandwidth with up to 2400 selectable frequencies and a multifunction backup-frequency button. This system ships in the EE1 band (530.000-589.975 MHz) with an operating range up to 100 m (300 ft).
| Type | Frequency-agile UHF wireless microphone system |
|---|---|
| Series | 3000 Series (fourth generation) |
| Configuration | Single channel |
| Receiver | ATW-R3210 (true diversity) |
| Transmitter | ATW-T3202 handheld |
| Capsule | ATW-C510 cardioid dynamic (interchangeable) |
| Capsule Frequency Response | 90 Hz-16 kHz |
| Frequency Band | EE1 (530.000-589.975 MHz) |
| Tuning Bandwidth | 60 MHz, up to 2400 selectable frequencies |
| Range | Up to 100 m (300 ft) |
