American DJ Scene Setter 24-Channel DMX Dimming Console
The Scene Setter is a two-scene preset desk for conventional dimming: 24 faders on the A bank, 24 on the B bank, and a crossfader between them. That is the layout house electricians and mobile operators already know, so a substitute can walk up to it and run a show.
Memory holds 11,000 programmable scenes and 48 chases arranged as 12 x 4 pages, with up to 1,000 steps per chase, and both are password protected against a curious guest. Twenty-four bump buttons sit under the faders for solo or pile-on operation, and Blind and Dark functions plus Tap Sync with independent speed and fade control cover the live pass.
| Channels | 24 conventional dimming channels |
|---|---|
| Operation | Two scene, A/B faders |
| Scenes | 11,000 programmable, password protected |
| Chases | 48 programmable stacks, 12 x 4 pages, password protected |
| Steps per Chase | Up to 1,000 scenes |
| Faders | 24 individual channel faders |
| Bump Buttons | 24, with Solo and Pile On chase operation |
| Functions | Blind and Dark, Tap Sync, independent speed and fade control |
