AC Infinity AIRPLATE T9 Cabinet Cooling Fan

The AIRPLATE T9 steps up to an 18-inch fan for cabinets and equipment enclosures that need more total airflow than the smaller AIRPLATE models move, still governed by an LCD thermal controller rather than a fixed manual switch. The controller reads a probe inside the cabinet and adjusts fan speed automatically as equipment heats up, with six speed steps and a backlit display for checking status at a glance.

It shares the same CNC-machined aluminum construction and dual ball bearings as the rest of the AIRPLATE line, rated for a 67,000-hour service life, and the controller can manage additional compatible AC Infinity fans from one panel. It mounts into a cutout in the cabinet the same way the smaller models do.

Fan Diameter18 in.
Control TypeLCD temperature controller
BearingsDual Ball, 67,000-hour L10 life
MaterialsCNC-machined aluminum frame
Operating Temperature0 - 158 deg F
Operating Humidity35 - 85% RH
Wall Adapter Input100 - 240V AC
