AC Infinity AIRPLATE T3 Cabinet Cooling Fan
The AIRPLATE T3 mounts into a home theater cabinet or AV equipment enclosure and pairs a 6-inch fan with an LCD thermal controller instead of a fixed manual speed switch. The controller reads a probe planted inside the cabinet and steps the fan speed up or down automatically as the equipment heats and cools, so the cabinet stays within a safe operating range without a manual adjustment.
It is built from CNC-machined aluminum with dual ball bearings rated for 67,000 hours of continuous duty, and it can control additional compatible AC Infinity fans from the same controller. Power comes from a standard wall outlet through the included adapter, with a six-foot cord and probe long enough to reach the back of most cabinets.
| Fan Diameter | 6 in. |
|---|---|
| Control Type | LCD temperature controller |
| Bearings | Dual Ball, 67,000-hour L10 life |
| Materials | CNC-machined aluminum frame |
| Operating Temperature | 0 - 158 deg F |
| Operating Humidity | 35 - 85% RH |
| Wall Adapter Input | 100 - 240V AC |
| Cord/Probe Length | 72 in. (6 ft) |
