AC Infinity AIRPLATE S9 Cabinet Cooling Fan
The AIRPLATE S9 mounts into the back or side panel of a home theater cabinet, equipment rack, or AV closet and moves warm air out before it builds up around amplifiers, receivers, and switchers. A manual speed controller sets the fan to whichever of its speed steps keeps the cabinet cool without adding noise to the room, and the whole unit is built from CNC-machined aluminum rather than stamped plastic.
Dual ball bearings rated for 67,000 hours keep it running quietly for years of continuous duty, and the enclosed fan design tucks behind a vent grille instead of sitting exposed in a rack. It plugs into a standard wall outlet through the included power adapter, so it drops into an existing cabinet without any rewiring.
| Fan Diameter | 18 in. |
|---|---|
| Control Type | Manual speed controller |
| Bearings | Dual Ball, 67,000-hour L10 life |
| Materials | CNC-machined aluminum frame |
| Operating Temperature | 0 - 158 deg F |
| Operating Humidity | 35 - 85% RH |
| Wall Adapter Input | 100 - 240V AC |
| Mounting | Horizontal or vertical |
