VigilLink VLSW-51H20 5x1 HDMI 2.0 Switcher, 18Gbps

The VLSW-51H20 routes any of five HDMI sources to a single display at up to 4K2K@50/60Hz with YCbCr 4:4:4 sampling, across 18Gbps of bandwidth. Five inputs is the size that usually removes the need for a second switcher in a meeting room.

HDR10, Dolby Vision, and HLG are supported along with all HDMI 3D video formats. The switcher is HDCP 2.2/1.x and DVI 1.0 compliant.

HDCP Compliance	HDCP 2.2/1.x
Video Bandwidth	18Gbps
Video Resolution	Up to 4k2k@60Hz
Input Ports	5xHDMI Type A (19-pin female) 1xIR IN [3.5mm Stereo Mini-jack]
Output Ports	1xHDMI Type A (19-pin female)
HDMI Audio Formats	PCM2.0/5.1/7.1CH, Dolby 5.1, DTS 5.1, Dolby True HD, DTS-HD Master Audio
Color Space	RGB, YCbCr 4:4:4 / 4:2:2. YUV 4:4:4
Color Depth	8-bit (4K60Hz)
