Universal Audio 6176 Vintage Channel Strip

The 6176 is the two halves of a Universal Audio front end in one 2U box: the all-tube 610 mic preamp derived from the Bill Putnam modular console, and the Class A 1176LN FET compressor. A Split / Join switch runs them in series as a channel strip or splits them so each can be patched independently.

The preamp gives up to 65 dB of gain with selectable 500 ohm or 2k input impedance, high and low shelving EQ, and mic, balanced line and Hi-Z inputs. Signal-to-noise is better than 90 dB at maximum gain, and two units interconnect for stereo through the 1176-SA. Hand-built in the USA with a one-year limited warranty.

Type	Tube mic preamp and FET compressor channel strip
Preamp	All-tube 610 circuit, maximum gain 65 dB
Compressor	1176LN Class A FET, gain 40 dB
Mic Input Impedance	Selectable, 500 ohms or 2k
Hi-Z Input Impedance	Selectable between 2.2 Mohms or 47 kohms
Frequency Response	20 Hz to 20 kHz, +0 / -1 dB
Signal-to-Noise Ratio	> 90 dB (at maximum gain)
Routing	Split or Join switch for series or independent operation
