Theatrixx xVision DisplayPort to Quad-SDI Reversible Module - XVVRMDP2QSDI

XVVRMDP2QSDI is a Theatrixx xVision reversible module: a rack card that slides into the XVVRF8 8-bay frame and can be fitted facing front or rear, so the connectors land on whichever side of the rack you cable from. It takes a computer output to SDI for the video system. Input is 1 x DisplayPort 1.2 and output is 4 x 3G/HD/SD SDI BNC (Quad-Link). A reclocked and amplified loop-thru on 1 x Tri-level sync (BNC) lets a local monitor tap the same feed.

Power is Reversible redundant power fed by XVVRF8, (8-Bay Rackmount Frame). Draw is 20W. The frame supplies redundant power to every slot, so a module has no wall-wart of its own and no separate mains run to lose.
