Tascam MM-2D-X 2-Channel Dante Converter with DSP Mixer

The MM-2D-X puts two mic or line inputs and two line outputs on a Dante network from a half-rack box, with +48 V phantom power and remotely controllable mic gain so the preamps can be trimmed from a control room. Four Dante channels are available in each direction, and an internal DSP mixer handles matrixing without a separate processor.

Power over Ethernet means one Cat cable does data and power, which is what makes the unit practical at a lectern or a ceiling location; a TASCAM PS-P1220E adapter is available where PoE is not. Conversion covers 44.1 to 96 kHz at 16 or 24-bit, minimum input level is -74 dBu, and the unit draws 6 W.

General Formats and channels	44.1/48/88.2/96kHz,16/24-bit, 2 channels
ANALOG IN connectors Minimun input level	-74 dBu
ANALOG OUT connectors Nominal output levels	+4 dBu (when Ref. Level not -9 dBFS) +6 dBu (when Ref. Level set to -9 dBFS)
DATA/DATA+PoE connectors Connector	RJ-45
DATA/DATA+PoE connectors Gigabit Ethernet standard	1000BASE-T (IEEE 802.3ab)
DATA/DATA+PoE connectors Transmission protocol	Dante
ANALOG OUT connectors Power	PoE class 0 TASCAM PS-P1220E AC adapter (sold separately)
ANALOG OUT connectors Dimensions	214 x 44.45 x 136.1 mm (W x H x D, including protrusions)
