Symetrix W4 Wall Controller

The W4 is a networked wall remote for Symetrix IP DSP systems. Its control surface is One rotary encoder with push-button knob and 8 push-button switches, paired with a high-contrast OLED display that you label in Composer, so the panel names the rooms, sources and presets a given space actually uses rather than generic channel numbers. Multi-language and symbol labelling is supported, which matters when the same building runs in more than one language.

It runs over ordinary Ethernet and takes its power from the same cable: one PoE 802.3af drop feeds the panel, so there is no local supply to find a box for. The housing sits in a Double gang, Decora form factor and accepts standard Decora faceplates, in black or white, US or Euro where offered. Because it speaks the same standard IP infrastructure as the DSP, it drops into the network you already ran rather than needing a control bus of its own.
