SWIT CL-120D 120W Bi-Color SMD LED Panel Light
The CL-120D is the larger 2:1 panel in the CL series, running 120W for 3700 lux at one metre on centre. The wider aspect suits a two-shot or an interview setup where a square panel would need to be pulled back further than the room allows.
Everything else matches the CL-60D: SMD emitters for an evenly spread field, 0 to 100 percent PWM dimming without flicker, continuous colour temperature from 2700K to 6500K in 50K steps, and CRI 98 with TLCI 99. DMX512 runs on 5-pin XLR in and out, a rear LCD reads dimmer, colour temperature, DMX address and battery state, and power is 11 to 17V on 4-pin XLR from a battery plate or an AC-DC adaptor. The LA-G120 honeycomb is the matching accessory.
| Power | 120 W |
|---|---|
| Output | 3700 lux at 1 m, centre |
| Panel Aspect | 2:1 |
| Colour Temperature | 2700K to 6500K, continuously adjustable in 50K steps |
| Colour Rendering | CRI 98, TLCI 99 |
| Dimming | 0 to 100 percent PWM, flicker free |
| DMX | DMX512 on 5-pin XLR in and out |
| Power Input | DC 11 to 17V on 4-pin XLR, battery plate or AC-DC adaptor |
| Accessory | Optional LA-G120 honeycomb |
