Name: LEA Professional Connect 124 4-Channel Smart Amplifier
Brand: LEA Professional
SKU: CS124
Availability: InStock

The LEA Professional Connect 124 is an IoT-enabled install amplifier with 4 channels rated at 120 W each into 4 ohms, 8 ohms, 70V or 100V, with impedance selectable per channel so a single unit can feed low-impedance and constant-voltage zones at the same time. It covers larger retail and restaurant zones, classroom clusters, and residential systems where the equipment closet has no room to spare.

Setup and monitoring run in a web browser with no software to install, reached through the amplifier's own Wi-Fi access point, an existing wireless network, or a wired LAN, and the same interface is available remotely through LEA Cloud. Onboard processing is a 96 kHz Analog Devices Sigma DSP with a routable input matrix, 48 dB per octave crossovers, eight bands of parametric EQ per channel, user-adjustable speaker limiters, and real-time load monitoring. An external I/O port handles remote power and fault reporting, and the universal switch-mode supply with power factor correction runs on anything from 100 to 240 VAC. The D models add Dante audio over IP alongside the analog inputs.

Channels	4
Output per Channel	120 W at 4 ohms, 8 ohms, 70V and 100V; 60 W at 2 ohms
Amplifier Class	Class D with Smart Power Bridge, bridged output without sacrificing a channel
Inputs	Balanced analog, user-selectable 26 dB / 34 dB input sensitivity
THD+N	0.1% (20 Hz to 20 kHz)
Frequency Response	20 Hz - 20 kHz, +/- 0.5 dB at 4, 8 ohms, 70V and 100V
Signal to Noise	105 dB (20 Hz to 20 kHz, referenced to 8 ohms)
DSP	Analog Devices Sigma 96 kHz, 32-bit core, 48 dB/oct crossovers, 8 parametric EQ, limiters
Power Supply	Universal switch-mode with PFC, 100 - 240 VAC +/- 15%
Dimensions	11.82 x 8.58 x 1.71 in (300.11 x 218 x 43.5 mm), half rack
Weight	7 lb (4.1 kg)
