Electro-Voice EVID-S5.2T 70V Surface-Mount Loudspeaker

The EVID-S5.2T steps up to a 5.25 inch woofer and a 0.75 inch tweeter in the same fire-rated ABS enclosure family as the rest of the EVID-S line, aimed at background music and paging zones that need more headroom than the 4 inch model. A 30 W transformer switches between 3.7, 7.5, 15, or 30 W taps at 70V or 100V, or bypasses to 8 ohms for a direct amplifier feed.

A rear high-pass recommendation of 60 Hz keeps the small woofer out of trouble when it is paired with a subwoofer, and the same rotating bracket used across the S-series lets it sit flush on a wall or angle down from a ceiling edge. It is IP54 rated for damp locations and ships in black or white.

Driver complement5.25 in (133 mm) woofer, 0.75 in (20 mm) tweeter
Frequency response (-3 dB)85 Hz - 20 kHz
Transformer taps3.7 W (70V only), 7.5 W, 15 W, 30 W, or 8 ohm bypass
Power handling75 W
Maximum SPL109 dB (1 m), 115 dB peak
Sensitivity90 dB (1W/1m)
Coverage90 degrees nominal (-6 dB), horizontal and vertical
Environmental ratingIP54 per IEC-60529
