ESE ES-217 Audio Distribution Amplifier

The ES-217 is a 1x4 audio distribution amplifier that splits one audio source into four isolated outputs. Terminal-block connectors make it suited to permanent installations where feeds are wired once and left in place. Balanced or unbalanced connections are supported at 600 ohms, and its transformerless design keeps the signal path clean.

Gain is variable and adjustable independently for each output, up to +18 dB maximum, so every destination can be set to its own level. The amplifier can also pass SMPTE and IRIG time codes, making it useful in timing distribution as well as audio. It is built for 110-120 VAC standard, with 220-240 VAC and UL options available.
