DVDO Matrix-44SS-MV-VW 4K 4x4 Seamless HDMI Matrix Switcher & Video Wall Controller with Multiview

The Matrix-44SS-MV-VW is DVDO's 4K 4x4 Seamless HDMI Matrix Switcher & Video Wall Controller with Multiview. HDMI 2.0 / HDCP 2.2 compliant.

Supports video resolutions up to 4K@60Hz 4:4:4 at an 18Gbps video bandwidth. Seamless switching between inputs. 12 display modes with multiview function and 9 display modes with video wall function. Audio embedding and de-embedding with separate audio inputs and outputs. HDMI audio formats: LPCM, Dolby Digital/Plus/EX, Dolby True HD, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio.

HDCP	HDMI 2.0 / HDCP 2.2 compliant
Video	Supports video resolutions up to 4K@60Hz 4:4:4 at an 18Gbps video bandwidth
Signal Handling	Seamless switching between inputs
Feature	12 display modes with multiview function and 9 display modes with video wall function
Audio	Audio embedding and de-embedding with separate audio inputs and outputs
Connectivity	HDMI audio formats: LPCM, Dolby Digital/Plus/EX, Dolby True HD, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio
Control	CEC control & advanced EDID management
Optics	Control via front panel buttons, IR remote, RS-232, and IP (web GUI)
Part Number	DVDO-Matrix-44SS-MV-VW
