Crown XTi 1002 DriveCore Amplifier
The XTi 1002 pairs 500 W per channel at 4 ohms (700 W at 2 ohms) with onboard DSP: Peakx Plus limiters with adjustable threshold, attack, and release, plus a subharmonic synthesizer for extending low end on undersized cabinets. Fifty onboard presets, 49 of them user-definable, cover most speaker-protection and tuning needs without a laptop.
Three user-selectable fan modes trade noise for cooling depending on the room, and onboard monitoring watches AC line voltage and power-supply temperature so a fault shows up on the front panel instead of as a dead channel mid-show. HiQnet System Architect compatibility brings it into a networked system alongside other Crown and Harman gear when a room needs central control.
| Configuration | 2-channel amplifier with onboard DSP |
|---|---|
| Power @ 4 ohms | 500 W per channel |
| Power @ 8 ohms | 275 W per channel |
| Power @ 2 ohms | 700 W per channel |
| DSP | Peakx Plus limiters, subharmonic synth, 50 presets (49 user) |
| Networking | HiQnet System Architect compatible |
| Dimensions | 19 in W x 3.5 in H x 12.25 in D |
| Weight | 18.5 lb (8.4 kg) |
