Crown XTi 4002 DriveCore Amplifier
The XTi 4002 delivers 1200 W per side at 4 ohms and adds PeakX Plus limiters with user control over threshold, attack, and release, so system protection is tuned to the loudspeaker rather than left at a factory guess. The XTi 2 series is built for portable PA that gets loaded in and out several nights a week.
An enhanced subharmonic synth section with control over frequency, gain, and filter type lets a small system fill in low end it cannot otherwise produce, and three fan modes match cooling noise to the room. Cast-aluminium handles are integrated into the chassis for the part of the job that happens in a hallway.
| Channels | 2 |
|---|---|
| Sensitivity | 1.4V |
| Rated Power Output (per channel) | 1600W 2 ohms, 1200W 4 ohms, 650W 8 ohms |
| Signal to Noise Ratio (below rated 1 kHz power at 8 ohms) | 100 dB (A-weighted) |
| THD | < 0.5% |
| Frequency Response (at 1W, 20 Hz - 20 kHz) | + 0 dB, -1 dB |
| Dimensions | 3.5" x 19" x 12.25" |
| Weight | 18.5 lbs (8.4 kg) |
