Crestron DM-NVX-384C DM NVX 5K 4x1 AV-over-IP Switcher Card with HDMI and USB-C Connectivity

The Crestron DM-NVX-384C is a DM NVX 5K 4x1 AV-over-IP Switcher Card with HDMI and USB-C Connectivity. DM NVX carries the signal as a stream over standard Gigabit Ethernet, which makes the network switch the matrix and lets a system grow by adding endpoints instead of replacing a chassis.

Copy protection is HDCP 2.3, AES-128, PKI. Bit rates are 200 to 950 Mbps. Streaming uses RTP, SDP. It is set up and monitored from the same Crestron control program and XiO Cloud account as the rest of the estate.

Video Resolutions	Up to 5120x2880 @30 Hz (5K Wide) or 5120x1440 @60 Hz (5K Super-Wide); Up to 4:4:4 color sampling; HDR10, HDR10+, Dolby Vision, and Deep Color support
Audio Formats	Primary multichannel (up to 8-channel LPCM or encoded HBR 7.1 surround sound), secondary 2-channel LPCM
Bit Rates	200 to 950 Mbps
Streaming Protocols	RTP, SDP
Copy Protection	HDCP 2.3, AES-128, PKI
Input Signal Types	HDMI with HDR10, HDR10+, Dolby Vision, Deep Color, and 5K support (Dual-Mode DisplayPort interface and DVI compatible) DisplayPort over USB-C (DisplayPort Alt Mode) with HDR10, HDR10+, and 5K support
Output Signal Types	HDMI with HDR10, HDR10+, Dolby Vision, Deep Color, and 4K60 4:4:4 support (DVI compatible)
Container	MPEG-2 transport stream (.ts)
