Blackmagic URSA Cine Immersive Body
The URSA Cine Immersive Body is the body only version of Blackmagic's dual lens camera for Apple Immersive Video. Two fixed custom lenses record a stereoscopic 8160 x 7200 image per eye at up to 90 fps, with the lens geometry calibrated at the factory and carried in the file so DaVinci Resolve reads it directly.
It records Blackmagic RAW to the URSA Cine Media Module, and the body only configuration is for operators who already own the media module, viewfinder and battery plates and are adding a second body or replacing one. The generation 5 Color Science sensor gives 16 stops of dynamic range with built in ND filters and dual native ISO.
| Sensors | 2 x 8K sensors. / Left eye and right eye. |
|---|---|
| Effective Sensor Size | 23.66 mm x 20.88 mm each. |
| Pixel Pitch | 2.9 microns. |
| Lens | Fixed focal length, 180 deg + field of view, stereo lens pair. |
| Dynamic Range | 16 Stops. |
| Shooting Formats | 8160 x 7200 x 2 (stereo immersive) |
| Frame Rates | Project frame rates of 23.98, 24, 25, 29.97, 30, 50, 59.94, 60 and 90 fps supported. |
| Part Number | BMD-CINEURSAAF24DS/IMA0BD |
