Aviom D400 A-Net Distributor
The D400 is the box that sits between the console and the musicians. It takes the channel feed in and fans it out to eight powered RJ45 A-Net outputs, each one carrying both the audio and the 24 VDC that runs a personal mixer, so a player only needs a single Cat-5e cable at their position. A ninth unpowered Pro16e output daisy-chains to another distributor when the band outgrows eight mixers.
Two input versions are stocked. The D400 accepts Pro16e A-Net from an Aviom input module. The D400-Dante instead has primary and secondary Dante RJ45 ports and pulls 32 channels straight off a Dante network at 44.1 or 48 kHz, which removes the need for separate input cards when the console is already on Dante. Both are 2U, 19 x 7.25 x 3.5 inches, 12 lbs, and feed A640, A360, A320, and A-16II mixers.
| A-Net Outputs | Eight powered RJ45 for personal mixers, plus one unpowered Pro16e output for expansion |
|---|---|
| Input (D400) | Pro16e Aviom A-Net |
| Input (D400-Dante) | Primary and secondary Dante RJ45, 32 channels at 44.1 / 48 kHz |
| Power to Mixers | 24 VDC, 0.5 A over the Cat-5e cable |
| Compatible Mixers | A640, A360, A320, A-16II |
| Format | 2U rack |
| Dimensions | 19 in wide x 7.25 in deep x 3.5 in high |
| Weight | 12.0 lbs (5.44 kg) |
| Power Input | 100 - 120 VAC or 200 - 240 VAC (selector switch), 50 - 60 Hz, 220 W max |
