Aida Imaging UHD-X3L 3x Zoom 4K UHD POV Camera
The AIDA UHD-X3L pairs a 1/2.5-inch progressive CMOS sensor with a built-in 3x optical zoom lens (3.85mm wide to 13.4mm tele) to deliver 2160p UHD video over a single HDMI 1.4 output. It records at up to 4K/30fps, or drops to 1080p or 720p at up to 60fps when full-frame-rate HD is the priority, all in the same compact box camera body AIDA uses across its POV line.
Camera control runs over RS-485 VISCA with an on-board OSD button for local adjustment, and the housing measures a compact 48 x 48 x 83.09mm at 140 grams, small enough to mount discreetly in a broadcast set, classroom, or telemedicine cart. It ships ready to run on 12V DC power (9-15V range), making it a straightforward upgrade path for any HDMI-based production wanting UHD resolution without a full camera rebuild.
| Sensor | 1/2.5-inch progressive CMOS, 3840 x 2202 effective pixels |
|---|---|
| Lens | 3x optical zoom, 3.85mm (wide) - 13.4mm (tele) |
| Output | HDMI 1.4 |
| Resolution | 2160p 30fps; 1080p and 720p up to 60fps |
| Color Space | 4:2:2 (YCbCr) 10-bit |
| Control | RS-485 VISCA, OSD button |
| Dimensions / Weight | 48 x 48 x 83.09mm (1.89" x 1.89" x 3.27"), 140g |
| Power | 12V DC (+9 to +15V DC) |
