AceBackstage Standard Back Box for Full Stage Pockets

The Standard Back Box for Full Stage Pockets is the rough-in box that the matching AceBackstage stage pocket drops into. It is set into the floor before the pour or the deck goes down, braced to carry the same load as the floor around it, and the predrilled flange sandwiches the pocket bezel to the box. Floor cut out is 10" x 10".

Ordering options: 6 inches deep / 8 inches deep / 12 inches deep. Pick one above and the part number and price follow it. Under floor depth 6". Conduit lands on any side through the combination knockouts. The pocket, lid and connector panel are ordered separately.

Part Numbers	102BBX, 1028BBX, 102DDBBX
Floor Cut Out	10" x 10"
Under Floor Depth	6" / 8" / 12"
Item	Rough In Box, 6 inches deep for use with Full Size Stage Pockets
Work Clearance	Standard 6 inch deep Back Boxes provide 1.5 inches of clearance below the installed pocket.
Knockouts	Combination knockouts are positioned in two places on opposing sides, with 1/2, 3/4, 1, and 1 1/4 inch options.
Brand	AceBackstage
