AceBackstage Back Access Cover for Double Wide Stage Pockets

The Back Access Cover for Double Wide Stage Pockets is the rough-in box that the matching AceBackstage stage pocket drops into. It is set into the floor before the pour or the deck goes down, braced to carry the same load as the floor around it, and the predrilled flange sandwiches the pocket bezel to the box. Floor cut out is 10" x 18".

Ordering options: UL Approved Back Access Cover for use with Double Wide Size Pocket / UL Approved Isolated Back Access Cover for use with Double Wide Size Pocket. Pick one above and the part number and price follow it. Under floor depth 4.5". Conduit lands on any side through the combination knockouts. The pocket, lid and connector panel are ordered separately.

Part Numbers	24BAC, ISO24BAC
Floor Cut Out	10" x 18"
Under Floor Depth	4.5"
Item	UL Approved Back Access Cover for use with Double Wide Size Pocket
Timely Assembly	The BAC is smaller than the stage pocket floor cut out and can be easily pulled through for assembly to the pocket after early phase conduit connection during the rough-in stage.
Knockouts	Combination knockouts are positioned in four places, with 1/2 and 3/4 inch options.
UL Listed / Made Strong	BACs are tool and die fabricated to exactly match the back access opening of a Double Wide Stage Pocket.
Brand	AceBackstage
