Williams AV Body-pack charger, 12 bay

The Williams AV CHG 3512. Drop-in, 12-unit charger for body-pack style transmitters and receivers.(For use in US). 12-1/4" x 11" x 2-3/8", 2.48 lbs. Includes Power Supply.

For use with: PLR BP1 Loop receiver PPA R37 FM receiver PPA R38 FM receiver PPA T46 FM transmitter WIR RX22-4 Infrared receiver Ordered as part number CHG 3512. Published dimensions, power and warranty are in the specifications tab.

Part NumberCHG 3512
CategoryAccessories, Chargers / Power Supplies / Batteries, ProAV
Size:9.5"L x 7.4"W x 1.7"H (24.1 cm L x 18.8 cm W x 4.3 cm H)
Weight:1.2 lbs (.54 kg), excluding power supply
Color:Black ABS
Power Supply Input:90 - 240 VAC input
Power Supply:TFP 037 Switching AC adapter, 5 VDC - 4A output
Charging Rate:16 Hour Charge: 140 mA Pulse/Maintain: 140 mA
Weight2.48 lbs
Connector1/4"
Capacity12 bay
BrandWilliams AV
