Whirlwind pcDIhw Stereo Direct Box

The pcDIhw is the pcDI with the mini jack lead built in: a hardwired 30 inch tail terminated in a 3.5 mm stereo plug. In a rental stock or an install rack that one detail matters, because the cable that gets lost is always the little one.

Everything else matches the pcDI. Two separate DI channels, colour coded RCA in and through jacks and 1/4 inch TS inputs, colour coded XLR outputs, a stereo/mono switch, a 20 dB pad and a ground lift switch, all working through shielded TRHL-M transformers.

Type	Two-channel passive direct box
Input tail	30 in. hardwired 3.5 mm TRS plug
Transformer	Whirlwind TRHL-M with metal shield
Impedance ratio per channel	133:1
Frequency response	20 Hz - 20 kHz, +/-1 dB
Level change	-20 dB pad out, -40 dB pad in
Other inputs	Colour coded RCA in/through, 1/4 in. TS
Switches	Stereo/mono, 20 dB pad, ground lift
