Sony DC-78 Battery Power Unit for ECM Lavalier Microphones
The DC-78 is the power supply that turns a bare-capsule Sony lavalier into a microphone a mixer can use. The ECM-44BC, ECM-77BC, ECM-88BC and ECM-90BC all terminate in Sony's small four-pin connector and carry no electronics of their own; the DC-78 supplies them and presents a standard balanced XLR output at the other end.
It is the piece people forget to order and then cannot shoot without, so it belongs in every kit that carries a BC-type lavalier.
| Power requirements | LR-6 alkaline battery (AA size) |
|---|---|
| Battery life | Approx. 5,000 hours |
| Input connector | 4-pin (SMC9-4P), compatible with ECM-44BC/77BC/88BC and ECM-90BC |
| Output connector | XLR-3-12C type |
| Dimensions | Diameter - 20mm, Length - 144mm |
| Weight | Approx. 4.59 oz (with battery), 3.81 oz (without battery) |
