sE Electronics Z5600a II Multi-Pattern Tube Condenser Microphone
The Z5600a II is sE's long-running multi-pattern tube mic. A hand-crafted 1 inch true condenser with a gold-sputtered mylar diaphragm sits in front of a single 12AX7, and nine patterns run from omni through cardioid to figure-8 with three steps between each, chosen at the floor box so you are not reaching past a singer to change them.
Self-noise is 13 dB with 81 dB signal-to-noise. A 50 Hz low-cut and a 10 dB pad are switchable on the mic. The included power supply is the same floor-box format used by the RNT, and the mic itself weighs 850 g.
| Capsule | Hand-crafted 1 inch true condenser, gold-sputtered mylar |
|---|---|
| Tube Complement | 1x 12AX7 / ECC83 |
| Polar Patterns | 9 (omni, cardioid, figure-8 with three steps between each) |
| Frequency Range | 20 - 20,000 Hz |
| Sensitivity | 25 mV/Pa (-32 dBV) |
| Max SPL | 127 / 137 dB (0/10 dB pad) |
| Equivalent Noise Level | 13 dB |
| Powering | Included power supply unit, 200 Ohms, 3-pin male XLR |
