Martin Audio DX0.6 2-In 6-Out Network System Controller

DX0.6 is the six-output member of the DX0 controller pair, the one to reach for when a system needs more than four output legs: tops, subs and delays on one processor, or a three-way passive box with a separate sub feed. It carries the same factory presets for the Martin Audio passive range, so a FlexPoint, CDD or Blackline rig is aligned correctly the moment it is patched.

The audio path is identical to the DX0.4: 96kHz sampling, 118dB converter dynamic range, distortion below 0.003 percent and a 20Hz to 40kHz response within 0.3dB. Inputs get ten bands of parametric EQ with 0.1dB gain steps and there is a white and pink noise generator on board. Connection is two female XLR inputs and six male XLR outputs, with shielded RJ45 Ethernet, two RS485 RJ45 ports and a front-panel USB B socket. Mains input is 85 to 230VAC at 30W nominal.

Type	2 in, 6 out network loudspeaker system controller
Sample Rate	96kHz
Frequency Response	20Hz - 40kHz +0.3dB
Dynamic Range	118dB input A/D and output D/A
THD	Less than 0.003 percent at +4dBu, 1kHz
Audio I/O	2 x 3-pin female XLR in, 6 x 3-pin male XLR out
Control	Shielded RJ45 Ethernet, 2 x RS485 RJ45, front-panel USB B
Input EQ	10 band parametric, 15dB gain range
Max Input / Output Level	+20dBu in, +18dBu out
Power	85 - 230VAC 50-60Hz, 30W nominal
