JBL CSA-2120 2 x 120W Audio Amplifier

The CSA-2120 is a 2 x 120W audio amplifier. Frequency range is +/- 1dB (@1W into 4 or 8 Ohms). Sensitivity is 1.4Vrms.

It measures 8.2" x 1.7" x 7" (209 mm x 44 mm x 178 mm). In the box: Rack mounting kit. Compact size and light weight.

Type	2 x 120W Audio Amplifier
Output	120W @ 4/8 Ohms (1kHz Power, THD+N<0.5%)
Frequency Response	+/- 1dB (@1W into 4 or 8 Ohms)
Load Impedance	Stable from 2 - 16 Ohms
Sensitivity	1.4Vrms
Signal to Noise Ratio	Greater than 100 dB - 1kHz, A-weighted
Input Impedance	Balanced 20K Ohms/Unbalanced 10K Ohms
Max Input	+20dBu Typical
Dimensions	8.2" x 1.7" x 7" (209 mm x 44 mm x 178 mm)
