FSR DV-T6SS4K-41A 4x1 Presentation Scaling Auto-Switcher
The DV-T6SS4K-41A is the switcher FSR built to disappear into the furniture. Four HDMI inputs, one HDMI output at 4K 60Hz with HDR10, and a 1U chassis with mounting ears that goes under a table top, above a desktop, or straight inside a CT6 table box.
It switches to whichever source was plugged in last, which is the behaviour a room full of visiting laptops actually needs, and it can also be driven from the front panel, a remote push button interface, RS-232, IP or a Web GUI. FSR ships it preinstalled in the HV-QDKT-CT6 Quad Digital Kit.
| Product Type | 4x1 presentation scaling auto-switcher |
|---|---|
| Inputs | 4 x HDMI |
| Output | 1 x HDMI, 4K at 60Hz with HDR10 |
| Switching | Automatically switches to the most recently connected source |
| Control | Front panel, remote push button interface, RS-232, IP control, Web GUI |
| Chassis | 1U, mounting ears supplied |
| Mounting | Under a table, above a desktop, or inside the FSR CT6 table box |
| Kits | Supplied preinstalled in the HV-QDKT-CT6 Quad Digital Kit |
