FOR.A HVS-100PCI HDMI/VGA Input Card

The HVS-100PCI is a PC input card that combines HDMI and VGA terminals on a single board so computer and presentation sources can be switched alongside the HVS-100's video inputs. Two input channels are available: either two HDMI inputs, or one HDMI and one VGA input. Supported resolutions run from VGA and XGA up through WUXGA, plus 720p and 1080p HDTV formats.

A frame synchronizer and re-sizing engine on each input let asynchronous PC signals be re-sized and cut in cleanly with the switcher's other sources. The card fits expansion slot A or B on the HVS-100 main unit. Note that all resolutions are HDCP-incompatible, so protected content cannot be passed. It is compatible with both the HVS-100 and the HVS-100 Express.
