EtherWAN EL1032T 10/100BASE-TX to 100BASE-FX Industrial Media Converter with IEEE 802.3af 15.4W and IEEE 802.3at 30W PoE/PSE

The EtherWAN EL1032T is a 10/100BASE-TX to 100BASE-FX Industrial Media Converter with IEEE 802.3af 15.4W and IEEE 802.3at 30W PoE/PSE. It is ordered in 3 fibre configurations: Multi Mode (SC); Multi Mode (ST); Single Mode (SC) - 20Km (1310nm).

EtherWAN publishes input voltage 48-57VDC, operating temperature -10 to 60°C (14 to 140°F); Tested @ -20 to 70°C (-4 to 158°F), dimensions 70 x 110 x 30mm (W x D x H); (2.76" x 4.33" x 1.18"). Ordered as EtherWAN part number EL1032T-10B / EL1032T-20B / EL1032T-A0B. Specifications and photography as published by EtherWAN at etherwan.com/products/el1032t-series.

Ethernet Port	10/100BASE-TX: 1 port; 100BASE-FX: 1 port
PoE Power Output	IEEE 802.3at: up to 30W/port, 50-57VDC, 500mA Max.
Standards	IEEE 802.3 10BASE-T; IEEE 802.3u 100BASE-TX/FX; IEEE 802.3af/at PoE/PSE
Input Voltage	48-57VDC
Power Consumption	Device: Max. 3.6W (without PoE); PoE power budget: 30W Max. (depends on power input)
Operating Temperature	-10 to 60°C (14 to 140°F); Tested @ -20 to 70°C (-4 to 158°F)
Dimensions	70 x 110 x 30mm (W x D x H); (2.76" x 4.33" x 1.18")
Weight	0.25Kg (0.55lb.)
