Datavideo HBT-50 4-Channel HDBaseT Receiver with SDI and HDMI Outputs
The HBT-50 is the hub of a four-camera HDBaseT plant. Four RJ-45 inputs carry video, audio, control and PoE out to the camera positions at up to 100 metres on CAT6 cable, and each channel returns both an SDI and an HDMI output at up to 1080p60 simultaneously.
That dual output is the point: the SDI feeds the switcher while the HDMI feeds an ISO recorder or multiviewer, with no distribution amplifier in between. RS-232/RS-422 is broken out per channel and DVIP arrives on its own RJ-45, so a controller drives all four heads. Each channel supplies 65W of PoE to IEEE 802.3at, and the unit runs on AC mains.
| Function | 4-channel HDBaseT receiver |
|---|---|
| Video / Audio Input | HDBaseT x 4 with PoE (IEEE 802.3at), Cat6A shielded |
| Video / Audio Output | HDMI x 4 and SDI x 4, up to 1080p50/59.94/60 |
| Supported Formats | 1080p, 1080i, 720p |
| Control | DVIP RJ-45 x 1 input, RS-232 / RS-422 RJ-45 x 4 |
| PoE Output | 65W per channel |
| Distance | Up to 100m at 1080p60 over CAT6 |
| Power | AC input |
