DPA Microphones DPA UA0777 Nose Cone for 4006 Pencil Microphone
The 4006 is a pressure omni, which means its on-axis top end depends on what is fitted in front of the diaphragm. The UA0777 nose cone is one of the two ways DPA lets you change that: it gives a different high-frequency balance from the plain grid, without changing the microphone.
It screws directly onto the 4006 capsule housing. The APE spheres are the other option and go the other way, adding on-axis lift for distant placement.
| Type | Acoustic nose cone |
|---|---|
| Fits | DPA 4006 omnidirectional pencil microphone |
| Purpose | Alters the on-axis high-frequency response |
| Related | APE30RS, APE40RS and APE50RS pressure equalizer spheres |
